Indicator Plus Printer SONIC A9+P For Bench Scale, Floor Scale, Pallet Scale, Jembatan Timbang

Merk : SONIC
Type : A9P
Warranty : 1YEARS

SPECIFICATIONS :
Accuracy : Class III, n=3000
Conversion : type of A/D
Input signal range : -16 mV 18 mV
Conversion speed : 10 times/second
A/D resolution code : 1 million code
Calibration : All operation made by keys
Excitation power : DC, 5V, able to connect with 8pcs of 350 load cells or 16pcs of 700load cells
Display : 7 LED digit, 7 status indicating lights, 3 battery indicating lights.
Display circulation : 100ms
Division : 1/2/5/10/20/50/100 optional
Clock : Can display year/month/day, hour/minute/second, auto reap year and moth
Material for keys : Light touch type of pellicle
Scoreboard connection interface : Serial output
Transmission method : Current loop/ RS232 signal
Transmission data type : 11 bytes
Transmission distance : 30m
Baud rate : option 600/1200/2400/4800/9600
Transmission data format : 10 bytes: 1 byte is start, 8 data bytes (ASC II code), 1 byte is stop.
Transmission distance : RS-232 : 30m, RS-422/RS-485 : 1200m
Standard parallel output interface : To connect with TpuP 16 micro printer; wide line printer like M800 KX-P1121, KX-P1131, LQ1600K; POS58, T58D thermal micro printer. Built-in printer (for A9+P) Printing system: dot-matrix (96 dots each line), adopts M-150 II printing head or TpuP-16B printing head.
